Serrated Fold

Back to Library

Serrated Fold

Zig-zag Panels

The facade is defined by uniformly spaced, folded segments evenly split into a closed panel and glazing. The continuous folded configuration and angular geometry adds rhythm and depth to the surface. The closed, angled panels can be used for building-integrated-photovoltaics (BIPV).

Tags:

Single-Skin

Orthogonal Grid

3D/Sculpted Panels

Vertical

Metal

Low WWR Capable (< 40%), Passive Shading, BIPV Ready

Supported Inputs:

Plugins required:

Rhino Version:

Vertical surfaces & polysurfaces

Elefront

Already a member? Log in to download

Setup instructions:

Download the .GH Framework script.
Open Rhino, launch Grasshopper, and open the script.
Assign the name GH_Facet Facade to the surface or polysurface you want to apply the facade to. (Under Properties: Object > Name)
