Main Facade View
Moving Lines
Continuous Modulated Vertical Fins
A continuous exterior screen system defined by gently shifting fins. The vertical fins are kinked with subtly varying angles to create a dynamic, vertical exterior. The fins deliver effective passive shading against low-angle sun.

Tags:

Screen
Skin/ Wrapping / Monolithic
Fins
Vertical
Metal
Low WWR Capable (< 40%), Passive Shading

Supported Inputs:

Plugins required:

Rhino Version:

Vertical surfaces & polysurfaces

Elefront

8
Download .GH Framework
Subscribe to Download

Already a member? Log in to download

Request Early Access

Already a member? Log in to download

Setup instructions:

  1. Download the .GH Framework script.

  2. Open Rhino, launch Grasshopper, and open the script.

  3. Assign the name GH_Facet Facade to the surface or polysurface you want to apply the facade to. (Under Properties: Object > Name)
